Frame
Integrated suspension technology, Flex Pivot, adjustable head angle, Syncros cable integration system, BB92, UDH interface 12x148mm with 55mm chainline, Spark 27.5" carbon HMF
-
Fork
Manitou Machete Comp 27.5", 15x110, tapered, Air kids tune, 120mm travel
-
Rear shock
X-Fusion 02Pro R Trunnion KIDS, vertical valve position, rebound adjuster, Kids tune, 120mm travel, 165x45mm
-
Rear derailleur
SRAM SX Eagle 12 Speed
-
Shifters
SRAM NX Eagle Trigger, MMX
-
Crankset
Prowheel DMJ 30T 2PC, Boost CL:55, 155mm
-
BB-set
Prowheel PF92
-
Chain
SRAM CN SX Eagle
-
Cassette
SRAM NX Eagle, PG-1230, 11-50T, 12-Speed
-
Brake levers
Shimano BL-MT501
-
Brakes
Shimano BR-MT500
-
Rotor
SM-RT30, CL, 160mm
-
Handlebar
Syncros Alloy 6061 DBT shape Flat, 9°, 700mm
-
Grips
Syncros Performance XC lock-on grips
-
Stem
LEADTEC, 40mm, -/+7°, 31.8mm clamp
-
Seatpost
Syncros Dropper Ducan Kids Remote, 31.6mm, 80mm, Kid centric custom tune, Remote Lever I-Spec II
-
Seat
Syncros Future Pro
-
Headset
Syncros - Acros Angle adjust & Cable Routing HS System, -0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
-
Hubs
Front: Formula CL-811, 15x110mm; Rear: Formula CL-148S, 12x148mm
-
Spokes
Stainless Black 15G, 1.8mm
-
Rims
Syncros X-30SE, 32H, 30mm
-
Tires
Maxxis Rekon Race, 27.5x2.35", 120TPI, folding, EXO, TR
-
Approximate weight
12.5 kg / 27.56 lbs
-
Max. system weight
80 kg
-
Geometry (Size S) - Head tube angle
67.0°
-
Geometry (Size S) - Head tube length
90.0 mm
-
Geometry (Size S) - Top tube horizontal
565.9 mm
-
Geometry (Size S) - Standover height
711.0 mm
-
Geometry (Size S) - BB offset
-53.4 mm
-
Geometry (Size S) - BB height
301.1 mm
-
Geometry (Size S) - Wheel base
1,133.5 mm
-
Geometry (Size S) - BB center to top of seattube
415.0 mm
-
Geometry (Size S) - Seat angle
76.3°
-
Geometry (Size S) - Chainstay
437.5 mm
-
Geometry (Size S) - Reach
421.0 mm
-
Geometry (Size S) - Stack
591.4 mm
-
Geometry (Size S) - Fork length
510.0 mm
-
Geometry (Size S) - Maximum seatpost insertion
150.0 mm
