FrameGenius Carbon HMXIntegrated Suspension TechnologyVirtual 4 Link kinematic / Adjustable head angleSyncros Cable Integration SystemBB92 / UDH Interface / 12x148mm with 55mm Chainline
ForkFOX 36 Float Factory Grip 2 Air / KashimaHSC - LSC - HSR- LSR adjustable / Kabolt 15x110mm axle44mm offset / tapered steerer160mm travel
Rear ShockFOX FLOAT X NUDE Factory EVOL Piggy Back TrunnionKashima / SCOTT custom w. travel / geo adj.3 modes: Climb-Traction Control-DescendCustom large Air volume / Comp & Reb. Adj.Travel 150-100-Climb / T185X55mm
Remote SystemTracLoc TechnologyRear Suspension & Dropper Remote3 Rear Suspension modes
Rear DerailleurSRAM X01 Eagle AXS / 12 SpeedWireless Electronic Shift System
ShiftersSRAM GX Eagle AXS Rocker Controller
CranksetSRAM X01 DUB Eagle Carbon crankarm55mm CL / 32T
BB-SetSRAM DUB PF 92 MTB Wide / shell 41x92mm
ChainSRAM CN X01 Eagle
CassetteSRAM X01 XG1295 / 10-52 T
BrakesShimano XTR M9120 4 Piston Disc
RotorShimano SM-RT76 / 6 Bolt / 203/F and 180/R
HandlebarSyncros Hixon iC CarbonSize S & M 15mm rise / Size L & XL 25mm riseback sweep 8° / 780mmSyncros Endurance lock-on grips
SeatpostSyncros Duncan Dropper Post 1.531.6mm / S size 140mm / M size 160mmL size 170mm / XL size 200mm
SeatSyncros Tofino 1.5 RegularTitanium rails
HeadsetSyncros - Acros Angle adjust & Cable Routing HS SystemStainless / +-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
WheelsetSyncros Revelstoke 1.0-30 CLF: 15x110mm, R: 12x148mm30mm Tubeless ready Carbon rim 28HDT Swiss Ratchet Hubs / XD DriverSRAM TyreWiz / Syncros Axle w/Removable Leverwith 6mm Allen, T30 and T25 Tools
Front TireMaxxis Minion DHF / 2.6" / 120TPI FoldableTubeless Ready / EXO 3C maxxTerra
Rear TireMaxxis Dissector / 2.6" / 60TPI FoldableTubeless Ready / EXO 3C maxxTerra
ExtrasSRAM AXS PowerpackSRAM TyreWizSyncros Fork Fender
AccessoriesSyncros Eco SealantTransport Axle
Approx weights in KG13.3 (Tubeless setup)
Approx weights in LBS29.32 (Tubeless setup)
Max. System Weight128kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
