Frame
Alloy frame
Suspension Technology
Integrated suspension technology
Kinematic
Virtual 4 Link kinematic / Adjustable head angle
Cable Integration
Syncros cable integration system
System Interface
Bosch Smart System / UDH Interface / 12x148mm with 55mm chainline
Power Ready
Bosch PowerMore ready
Travel
Front: 170mm / Rear: 150mm
Fork
RockShox Domain R Air / E-Bike / Reb Adj. / QR Axle 15x110mm axle
Fork Details
44mm offset / tapered steerer / 170mm travel
Rear Shock
RockShox SuperDeluxe Piggy Back Trunnion / Reb Adj. / Large Air volume / Travel 150-100-Climb / T185X55mm
Drive Unit
Bosch Performance CX
Speed Limit
EU: 25kmh / INT: 20mph
Battery
PowerTube 800Wh
Display
Bosch System Controller
Remote
Mini remote
Charger
4A charger
Rear Derailleur
Shimano Deore RD-M6100 SGS
Derailleur Features
Shadow Plus / 12 Speed
Shifters
Shimano Deore SL-M6100-IR / Rapidfire Plus
Crankset
FSA Alloy
Chainguide
e*thirteen / e*spec Slider
Chainring
FSA 12Speed 34T chainring
Chain
Shimano CN-M6100
Cassette
Shimano CS-M6100 / 10-51
Brakes
Shimano Deore M6120 4-Piston Disc
Rotor
Front: SM-RT64 CL 220mm / Rear: SM-RT64 CL 203mm
Handlebar
Syncros Hixon 2.0 Alloy 6061
Handlebar Size
Size S & M 15mm rise / Size L & XL 25mm rise / back sweep 8° / 780mm
Grips
Syncros Endurance lock-on grips
Stem
Syncros AM 2.0
Stem Features
Syncros Cable Integration System / 4° rise / 6061 Alloy / 31.8mm / 1 1/8"
Seatpost
Syncros Duncan Dropper Post 2.5 / 31.6mm
Seatpost Sizes
S size 125mm / M size 150mm / L size 170mm / XL size 200mm
Seat
Syncros Tofino-E 2.5 Regular
Headset
Syncros - Acros Angle adjust & Cable Routing HS System / +-0.6° head angle adjustment
Headset Specs
ZS56/28.6 – ZS56/40 MTB
Front Hub
Formula CL-811 / 15x110mm
Rear Hub
Formula ECT-148M / Boost 148x12mm
Spokes
Stainless black
Rims
Syncros MD30 / 32H / 30mm / Pin Joint / Tubeless ready
Front Tire
Schwalbe Magic Mary 29x2.5"
Front Tire Features
SuperGravity / PSF / Ultra Soft / Tubeless ready / 120TPI Foldable Bead
Rear Tire
Schwalbe Explore 29x2.5"
Rear Tire Features
SuperGravity / PSF / Soft / Tubeless ready / 120TPI Foldable Bead
Lights
Syncros integrated rear fender light / Front light cable pre-installed
Approx Weight (KG)
25.9
Approx Weight (LBS)
57.1
Max System Weight
128kg
Weight Description
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
