Frame
Carbon Main Frame, Alloy SST-CST Integrated Suspension Technology Virtual 4 Link kinematic, Adjustable head angle Syncros Cable Integration System Bosch Smart System, UDH Interface, 12x148mm with 55mm Chainline, Bosch PowerMore Ready, Kickstand mount
-
Travel
Front: 150mm, Rear: 150mm
-
Fork
FOX 36 Factory Air, eMTB+, Grip X2, HSC - LSC - HSR - LSR adjustable, QR Axle 15x110mm axle 44mm offset, tapered steerer, 150mm travel
-
Rear Shock
FOX NUDE 6T Factory EVOL Trunnion SCOTT custom w. travel, geo adj. 3 modes: Lockout-Traction Control-Descend Low Speed Adj., Custom large Air volume, Reb. Adj. Bearing Hardware, Travel 150-100-Lockout, T185X55mm
-
Remote System
Suspension & Dropper Remote SCOTT TracLoc 2 Technology 3 modes
-
Drive Unit
EU: 25kmh, INT: 20mph Bosch Performance Line CX (BDU384Y)
-
Battery
PowerTube 800Wh
-
Display
Bosch System Controller, Mini Remote & Kiox 300
-
Charger
4A Charger
-
Rear Derailleur
SRAM X0 Eagle AXS Transmission 12 Speed Wireless Electronic Shift System
-
Shifters
SRAM AXS Rocker Pod Controller
-
Crankset
SRAM X0 Eagle, Alloy
-
Chainguide
e*thirteen, e*spec Slider
-
Chainring
SRAM Eagle Transmission 34T chainring
-
Chain
SRAM CN GX Eagle Transmission
-
Cassette
SRAM GX Eagle XS 1275 Transmission 10-52
-
Brakes
Shimano XT BR-M8220 4 Piston, Bosch ABS Pro
-
Rotor
Front: SM-RT66 220mm, Rear: SM-RT66 203mm
-
Handlebar
Syncros Hixon iC Carbon, Size S & M 15mm rise, Size L & XL 25mm rise back sweep 8°, 780mm Syncros Performance XC lock-on grips
-
Seatpost
Syncros Duncan Dropper Post 1.5s, Travel Adjust, 31.6mm S size 140mm, M size 180mm, L size 180mm, XL size 210mm
-
Seat
Syncros Tofino-E 1.5 Regular Titanium rails
-
Headset
Stainless, +-0.6° head angle adjustment Syncros - Acros Angle adjust & Cable Routing HS System ZS56/28.6 – ZS56/40 MTB
-
Wheelset
DT Swiss HXC1501, Hybrid, Carbon rims
-
Front Tire
Maxxis Forekaster 29x2.6" 120TPI Foldable Bead EXO, TR Tubeless ready 3C Maxx Terra
-
Rear Tire
Maxxis Forekaster 29x2.6" 120TPI Foldable Bead EXO, TR Tubeless ready 3C Maxx Terra
-
Lights
Syncros integrated rear fender light Front Light Cable pre-installed
-
Approx weight in KG
23.7
-
Approx weight in LBS
52.25
-
Max. System Weight
130kg The overall weight includes the bike, the rider, the equipment, and possible additional luggage
