Frame
Carbon HMFIntegrated Suspension TechnologyVirtual 4 Link kinematic / Adjustable head angleSyncros Cable Integration SystemTQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline Range Extender Ready
Travel
Front: 160mm / Rear: 155mm
Fork
FOX 36 Float Factory Air / Kashima FIT43 modes with low Speed adj. / Kabolt 15x110mm axle44mm offset / tapered steerer / Reb. Adj. / Lockout160mm travel
Rear Shock
FOX NUDE 6T Factory EVOL TrunnionSCOTT custom w. travel / geo adj.3 modes: Lockout-Traction Control-DescendLow Speed Adj. / Custom large Air volume / Kashima / Reb. Adj.Travel 155-100-Lockout / T185X55mm
Remote System
SCOTT TwinLoc 2 TechnologySuspension & Dropper Remote3 Suspension modes
Drive Unit
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
Battery
TQ Internal 360Wh + Range Extender 160Wh
Display
TQ HPRBluetooth / ANT+ / Dedicated Smartphone app
Charger
TQ 100-240V-4A
Rear Derailleur
SRAM XX Eagle AXS Transmission 12 SpeedWireless Electronic Shift System
Shifters
SRAM AXS Pod Ultimate Controller
Crankset
FSA Carbon crankset / 175mm / 34T
Chainguide
e*thirteen / e*spec Slider
Chainring
Scott custom spider / SRAM Eagle Transmission 34T chainring
Chain
SRAM CN XX Eagle Transmission
Cassette
SRAM XX Eagle XS 1297 Transmission 10-52
Brakes
SRAM Code Ultimate Stealth 4-Piston Disc
Rotor
SRAM HS2 Rotors F&R 200mm
Handlebar
Syncros Hixon iC CarbonSize S & M 15mm rise / Size L & XL 25mm riseback sweep 8° / 780mmSyncros Endurance lock-on grips
Seatpost
Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mmS size 140mm / M size 180mm / L & XL size 210mm
Seat
Syncros Tofino SL Regular 1.0Carbon rails
Headset
Syncros - Acros Angle adjust & Cable Routing HS SystemStainless / +-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
Wheelset
Syncros Revelstoke 1.0S-30 CLF: 15x110mmR: 12x148mm30mm Tubeless ready Carbon rim 28HDT Swiss 240 Ratchet EXP 36 / XD DriverSRAM TyreWiz / Syncros Axle w/Removable Leverwith 6mm AllenT30 and T25 Tools
Front Tire
Maxxis Dissector / 2.6" / 60TPI FoldableTubeless Ready / EXO 3C maxx Terra
Rear Tire
Maxxis Dissector / 2.6" / 60TPI FoldableTubeless Ready / EXO 3C maxx Terra
Extras
SRAM AXS Extension CordSRAM TyreWizSyncros Fork Fender
Approx weight in KG
17.9 (tubeless / without range extender)
Approx weight in LBS
39.46 (tubeless / without range extender)
Max. System Weight
128 kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
