Frame
Alloy S-XL=29"Integrated Suspension TechnologyVirtual 4 Link kinematic, Adjustable head angleSyncros Cable Integration SystemBosch Smart System, UDH Interface, 12x148mm with 55mm Chainline, Bosch PowerMore Ready
-
Travel
Front: 140mm, Rear: 140mm
-
Fork
FOX AWL 34, Grip Remote Damper 3P, 4QR Axle 15x110mm axle44mm offset, tapered steerer, 140mm travel
-
Rear Shock
FOX Float eRIDE 185x475mm, 3P, Remote Ready, 140mm Travel
-
Remote System
SCOTT TwinLoc Remote 3P
-
Drive Unit
Bosch Performance Line CX (BDU384Y)EU: 25kmh
-
Battery
PowerTube 800Wh
-
Display
Bosch System ControllerKiox 300Mini remote
-
Charger
4A Charger
-
Rear Derailleur
Shimano XT RD M8100SGS 12 Speed
-
Front Derailleur
SCOTT Chainguide
-
Shifters
Shimano XT SL-M8100IR
-
Crankset
FSA CK-745 165mm
-
Chainring
FSA 36T w/Chain Guard
-
Chain
KMC E12S
-
Cassette
Shimano CS-M8100-12 10-51T
-
Brakes
Magura MTC Allroad Disc Brakes, Bosch ABS Trail
-
Rotor
Front: MDR-C CL 203mm, Rear: MDR-C CL 203mm
-
Handlebar
Syncros Forged Alloy Combo 680mm, Back Sweep 9°, Up Sweep 8°, 70mm, with front Light mount and Kiox 300 mount
-
Seatpost
Syncros Duncan Dropper Post 2.531.6mm, S&M 361mm, L&XL 403mm
-
Seat
Syncros Tofino E 2.0
-
Headset
Syncros - Acros Angle adjust & Cable Routing HS SystemStainless, +-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
-
Hub (Front)
Formula CL-811, 15x110mm
-
Hub (Rear)
Formula CL-148M, Boost 12x148mm
-
Spokes
Sapim double butted
-
Rims
Syncros MD30, 32H, 30mm, Pin JointTubeless ready
-
Front Tire
Schwalbe Advancer 60-622 Wired
-
Rear Tire
Schwalbe Advancer 60-622 Wired
-
Lights
Lezyne Fusion E550SM front lightRear Supernova Taillight
-
Rack
Racktime SnapIt 2.0 15KG
-
Pedals
VP VPE-506
-
Extras
Curana alloy profile FenderUrsus Kickstand
-
Approx weight in KG
29
-
Approx weight in LBS
63.93
-
Max. System Weight
130kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
