FRAME
carbon, Tapered head tube, thru-axle M12 (1.75) x 148mm, disc brake Post Mount, Travel: 150mm
DRIVE UNIT
Flyon HPR120S, 25km/h
DISPLAY
Flyon The Display
BATTERY
Flyon The Battery, 630 Wh
CHARGER
Haibike The Battery Charger 4A
FORK
RockShox Yari RC Lockout, air, Travel: 150mm, aluminium steerer tube 1 1/8" - 1 1/2" tapered, thru-axle Boost
DAMPER
RockShox Deluxe RT, air
SHIFTING SYSTEM
Sram NX, 11 speed
GEAR LEVER
Sram NX, trigger switch
REAR SPROCKET
Sram PG1130, 11-42 teeth
CHAIN
Sram PC1110
CHAIN RING
Haibike Components The Chainring, 38, aluminium
BRAKE LEVER
Magura MT5 HC-lever, aluminium
FRONT BRAKE
Magura MT5, 203mm, 4-piston disc brake
REAR BRAKE
Magura MT5, 203mm, 4-piston disc brake
TYRES
Maxxis Minion DHF, 63-622, 29" x 2.5", foldable
REAR TYRE
Maxxis Minion DHR II, 71-584, 27.5" x 2.8", foldable
RIMS
Rodi Tryp 30, with eylets, hollow rim, aluminium
FRONT WHEEL HUB
Haibike Components TheHub ++ thru-axle 15x110mm
REAR WHEEL HUB
Haibike Components TheHub ++ thru-axle 12x148mm
SPOKES
DT Swiss Industry, black
HANDLEBAR
Haibike Components The Bar +++ DI2 Holes 780mm
GRIPS
Haibike MTB Griffe
STEM
Haibike Components TheStem 2, A-head, Bar bore: 31.8mm
HEAD SET
A-Head Tapered with steering stop, Cartridge, aluminium
SADDLE
Haibike Components TheSaddle
SEAT POST
XLC AllMtn, Remote, telescope, 34.9mm, aluminium
PEDALS
MTB platform pedal, aluminium
