FRAME
Genius Alloy SL 6011, custom butted / VLK Virtual 4 Link kinematic, 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) tire compatible with Geo-BB adj., TBC Trunnion box construction / Boost 12x148mm
FORK
RockShox Revelation RL3 Air, custom Charger 3-Mode Damper, 15x110mm Maxle Lite / 42mm offset / Tapered steerer, Lockout / Reb. Adj. / 150mm travel
REAR SHOCK
FOX Float EVOL Performace Trunnion, 3 modes / Lockout-Trail-Descend, DPS / Reb. Adj., Travel 150mm / 185X55mm
REMOTE SYSTEM
SCOTT TwinLoc TSP, Suspension-Seatpost Remote, below Bar / 3 modes / integ. Grip clamp
REAR DERAILLEUR
Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed
SHIFTERS
Shimano Deore SL-M6100-R / Rapidfire Plus
CRANKSET
Shimano FC-MT611-1, 32T
CHAINGUIDE
SCOTT custom
BB-SET
Shimano BB-MT500 / shell 41x92mm
CHAIN
Shimano Deore CN-M6100
CASSETTE
Shimano Deore CS-M6100-12 / 10-51 T
BRAKES
Shimano MT520 4 Piston Disc
ROTOR
Shimano SM-RT64 CL / 203/F and 180/R
HANDLEBAR
Syncros Hixon 2.0 / Alloy 6061D.B., 12mm rise / 9° / 780mm, Syncros Pro lock-on grips
H'STEM
Syncros FL2.0 / 6061 Alloy, 6° / integrated Top Cap / 31.8mm / 1 1/8"
SEATPOST
Syncros Duncan Dropper Post 2.5, 31.6mm / S size 100mm / M size 125mm / L & XL size 150mm
SEAT
Syncros Tofino 2.5 Regular
HEADSET
Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8", OD 50/62mm / ID 44/56mm
HUB (FRONT)
Shimano HB-MT410-B CL / 15x110mm
HUB (REAR)
Shimano FH-MT410-B CL / 12x148mm / Micro Spline
SPOKES
Stainless Black 15G / 1.8mm
RIMS
Syncros X-30S / 32H / 30mm / Sleeve Joint, Tubeless ready
FRONT TIRE
Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO
REAR TIRE
Maxxis Rekon / 2.6" / 60TPI Foldable, Tubeless Ready / EXO
APPROX WEIGHTS IN KG
14.80 (with tubes)
APPROX WEIGHTS IN LBS
32.63 (with tubes)
MAX. SYSTEM WEIGHT
128 kg
