FRAME
Genius Carbon / IMP Technology / HMF Main Frame, BB92 / Alloy SL 6011 swingarm, VLK Virtual 4 Link kinematic, 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) tire compatible with Geo-BB adj., SW dropouts for Boost 12x148mm, TBC Trunnion box construction
FORK
FOX 36 Float Rhythm Air Grip 3, 3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 150mm travel
REAR SHOCK
FOX Float EVOL Performace Trunnion, 3 modes / Lockout-Trail-Descend, DPS / Reb. Adj., Travel 150mm / 185X55mm / Contessa Custom Tune
REMOTE SYSTEM
SCOTT TwinLoc TSP, Suspension-Seatpost Remotebelow Bar / 3 modes / integ. Grip clamp
REAR DERAILLEUR
SRAM NX / Eagle 12 Speed
SHIFTERS
SRAM SX Eagle Trigger
CRANKSET
SRAM X1 Eagle DUB Boost, 30T
CHAINGUIDE
SCOTT custom
BB-SET
SRAM DUB PF integrated / shell 41x92mm
CHAIN
SRAM CN NX Eagle
CASSETTE
SRAM SX-PG1210 / 11-50 T
BRAKES
Shimano MT520 4 Piston Disc
ROTOR
Shimano SM-RT64 CL / 203/F and 180/R
HANDLE
BARSyncros Hixon 2.0 / Alloy 6061D.B., 12mm rise / 9° / 780mm, Syncros Pro lock-on grips
H'STEM
Syncros FL2.0 / 6061 Alloy, 6° / integrated Top Cap / 31.8mm / 1 1/8"
SEATPOST
Syncros Duncan Dropper Post 2.5, 31.6mm / S size 100mm / M size 125mm / L size 150mm
SEAT
Syncros Savona 2.0 (V-Concept) Channel
HEADSET
Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8", OD 50/62mm / ID 44/56mm
HUB (FRONT)
Formula CL-811 / 15x110mm
HUB (REAR)
Formula CL-148S / Boost 12x148mm
SPOKES
Stainless Black 15G / 1.8mm
RIMS
Syncros X-30S / 32H / 30mm / Sleeve Joint, Tubeless ready
FRONT TIRE
Maxxis Dissector / 2.6" / 60TPI Kevlar Bead, Tubeless Ready / EXO
REAR TIRE
Maxxis Rekon / 2.6" / 60TPI Kevlar Bead, Tubeless Ready / EXO
EXTRAS
Syncros Trail Fender
APPROX WEIGHTS IN KG
14.60 (with tubes)
APPROX WEIGHTS IN LBS
32.19 (with tubes)
MAX. SYSTEM WEIGHT
128 kg
