FRAME MATERIAL: Aluminium
FRAME: 7005 hydroformed aluminium, 3D forging, 170 mm F.O.L.D. kinematic, 148x12 mm thru axle, internal cable routing, post mount 203 mm
FORK: Rock Shox ZEB 29 Boost, Charger R, DebonAir, 110x15 mm, 44 mm rake, 170 mm travel
TRAVEL FORK: 170 mm
SHOCK:Rock Shox Super Deluxe Select+, 230/65 mm, hardware: 25,0 x 8 mm
MOTOR: Bosch Performance CX Gen4, 85 Nm, 250 W
BATTERY WATT-HOURS:625 Wh
BATTERY AMPERE HOURS: 16,7 Ah
DISPLAY: Bosch Purion
SHIFTER: SRAM GX Eagle
REAR DERAILLEUR: SRAM GX Eagle
SPROCKET: SRAM PG-1230 Eagle, 12-speed
CHAIN: SRAM NX Eagle
CRANKSET: Samox EC40 ISIS
TRANSMISSION OF DRIVE: front: 34, rear: 10-51
BOTTOM BRACKET: Integraded in Drive Unit
HANDLEBAR: FOCUS Trail, aluminium, riserbar, 780mm, rise: 30mm, backsweep: 9 degrees
GRIPS: FOCUS Locker SL
STEM: FOCUS C.I.S. integrated, 50 mm, 0 degrees, 35 mm, aluminium
HEADSET: Acros AZX-212 AH [1-1/8", tapered, 44/286-ZS56/40]
SADDLE: FOCUS Trail SL
SEATPOST: Kind Shock RAGE I, 31,6mm
BRAKES: SRAM Code R
BRAKE LEVER DESCRIPTION: SRAM Code R
BRAKE: Disc
RIMS: RODI TRYP30 FOCUS, eyelets
REAR HUB: Novatec D162 Disc, 12x148 mm
FRONT HUB: Novatec D041, 15x110 mm thru axle
TIRES: Schwalbe Magic Mary 2.6 Super Trail Soft
REAR TIRE: Schwalbe Magic Mary 2.6 Super Gravity Soft
GEARS: 12
BIKE WEIGHT INCL. BATTERY IN KG.: 25,95 kg
SIZE: 41,42,49,45
* Subject to technical modification without notice. Errors and omissions excepted.** Weight in size M, of standard specification and without pedals.
